Connectors & Ports | Video Audio Serial port USB port Network Power Supply |
HDMI Line level, stereo RS232, 115200 Bd max., mini-jack 3.5mm (power on/off) 2x USB 2.0 Ethernet 1GbE, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3az Input: 100-240V, 50-60Hz, Output: 5V DC 3.6A max. |
HDMI Line level, stereo RS232, 115200 Bd max., mini-jack 3.5mm (interactivity) 2x USB 2.0 2x Ethernet 1GbE, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3az Input: 100-240V, 50-60Hz, Output: 5V DC 3.6A max. |
Size & Weight | Size Weight |
Width: 5.9 / 150mm” Height: 0.9 / 23mm” Depth: 3.4 / 86.5mm” 12.3oz / 350g |
Width: 5.9 / 150mm” Height: 0.9 / 23mm” Depth: 3.4 / 86.5mm” 12.3oz / 350g |
Player Engine | Layer composition Animation Text Fonts Interactivity Video Wall Description languages Scripting language External data access |
Multi-layer, Elementi layout, apps Built-in playouts, apps, Elementi playlists, transitions, effects Unicode support (international text), Bidirectional (right-to-left, left-to-right) TrueType, OpenType user fonts, built-in fonts (Western, Cyrillic, Arabic, Greek, Hebrew, Chinese, Japanese, Korean, Thai, Hindi, etc.) USB input devices (touch screen, keyboard, mouse, presenter, barcode scanner, etc.) SVG Tiny 1.2+, Canvas, SMIL Animations, iCalendar (RFC2445) JavaScript (ECMAScript 5), jSignage™ (jQuery, Layers, Graph, QRCode, etc.), WebStorage, XMLHttpRequest, Node.js AJAX, REST, HTTP, raw TCP/UDP |
Multi-layer, Elementi layout, apps Built-in playouts, apps, Elementi playlists, transitions, effects Unicode support (international text), Bidirectional (right-to-left, left-to-right) TrueType, OpenType user fonts, built-in fonts (Western, Cyrillic, Arabic, Greek, Hebrew, Chinese, Japanese, Korean, Thai, Hindi, etc.) USB HID I/O, nework triggers, serial port (JavaScript serial API), USB input devices (touch screen, keyboard, mouse, presenter, barcode scanner, etc.) Accuracy ± 1 frame, unlimited screens SVG Tiny 1.2+, Canvas, SMIL Animations, iCalendar (RFC2445) JavaScript (ECMAScript 5), jSignage™ (jQuery, Layers, Graph, QRCode, etc.), WebStorage, XMLHttpRequest, Node.js AJAX, REST, HTTP, raw TCP/UDP |
Formats | Images Media file formats Video codecs Audio codecs Streaming protocols Data feeds |
JPEG, PNG, GIF, SVG MPG, MP4, M4V, M4A, MOV, MKV, MKA, WMV, WMA, AVI, VOB, TS, MP3, AAC, WAV Multi-video decoding capable, 1080p max, H.264/MPEG-4 AVC: HP@L4, H.264/MPEG-4 AVC: HP@L4, MPEG-2: MP@HL, MPEG-4: ASP, WM9/VC-1: AP@L3 AAC-LC, HE-AAC, MPEG Layer I, II, III (MP3), WMAv2, AC3 Built-in RSS app, Elementi feeds RSS, ICS, CSV, TXT, custom feeds (XML, JSON, JavaScript) |
JPEG, PNG, GIF, SVG MPG, MP4, M4V, M4A, MOV, MKV, MKA, WMV, WMA, AVI, VOB, TS, MP3, AAC, WAV MJPEG, Multi-video decoding capable, 1080p max, H.264/MPEG-4 AVC: HP@L4, H.264/MPEG-4 AVC: HP@L4, MPEG-2: MP@HL, MPEG- 4: ASP, WM9/VC-1: AP@L3 AAC-LC, HE-AAC, MPEG Layer I, II, III (MP3), WMAv2, AC3 RTSP, RTP, UDP (multicast capable) Built-in RSS app, Elementi feeds RSS, ICS, CSV, TXT, custom feeds (XML, JSON, JavaScript) |
Display | Aspect ratio Resolution Power on/off |
Aspect ratio 16:9, 16:10, 4:3 (horizontal, vertical) 1080p (1920x1080), 720p (1280x720), XGA (1024x768), VGA (640x480) at 50/60 Hz, etc. Serial port (simple protocol), DVI, HDMI-CEC |
Custom, 16:9, 16:10, 4:3 (horizontal, vertical) Custom, 1080p (1920x1080), 720p (1280x720), XGA (1024x768), VGA (640x480) at 50/60 Hz, etc. Serial port (advanced protocols), DVI, HDMI-CEC |
Network | Protocols Remote configuration Content transfer |
DHCP, static IP, Zeroconf, IPv4, IPv6, NTP, Bonjour, SNMPv1/v2c, HTTP, WebDAV Built-in HTTP server, RPC Web browser upload, live web server, scheduled download, direct upload, USB stick |
DHCP, static IP, Zeroconf, IPv4, IPv6, NTP, Bonjour, SNMPv1/v2c, HTTP, WebDAV Built-in HTTP server, RPC Web browser upload, live web server, scheduled download, direct upload, USB stick |
Storage | Internal External |
8GB solid state Flash drive, hard disk (via USB 2.0) |
16GB solid state Flash drive, hard disk (via USB 2.0) |
Characteristics | Processor Memory Power consumption Operating conditions Storage temperature Real-time clock (RTC) |
DaVinci DM8148 (ARM Cortex-A8 1GHz) RAM: 1 GB, DDR3-1066, Bandwidth: 4.3GB/s 8W Ambient temperature 32 - 104ºF / 0 - 40ºC Relative humidity 10-90% noncondensing Altitude 10,000ft / 3,000m max. -4 - 122ºF / -20 - 50ºC Accuracy ±1 min./month, backup by supercap (40 days) |
DaVinci DM8148 (ARM Cortex-A8 1GHz) RAM: 1 GB, DDR3-1066, Bandwidth: 4.3GB/s 8W Ambient temperature 32 - 104ºF / 0 - 40ºC Relative humidity 10-90% noncondensing Altitude 10,000ft / 3,000m max. -4 - 122ºF / -20 - 50ºC Accuracy ±1 min./month, backup by supercap (40 days) |
Tools | Built-in web-based content creation and scheduling tools | Built-in web-based content creation and scheduling tools | |
Warranty | 3 Year Limited Hardware Warranty | 3 Year Limited Hardware Warranty |
